RV Description
Star Boundless Versatility Off Road Motorhome is a typical multifunctional four-wheel drive vehicle. In addition to the basic characteristic of strong trafficability, this vehicle can also be used in multiple ways. This motorhome integrates the functions of an ordinary pickup motorhome, SUV, and motorhome.
The powerful twin-turbocharged diesel engine, BorgWarner's intelligent four-wheel drive system, and the standard-equipped central differential and rear axle differential lock ensure the trafficability of this off-road motorhome from the chassis. The metal frame with a full-cage King Kong structure, the lightweight box made of aluminum alloy stamping, and the low center-of-gravity driving height of only 2.2 meters ensure the unparalleled trafficability of this off-road motorhome in terms of power and structure.
In terms of driving space: The spacious double-row driving cabin is very comfortable. When driving, tall drivers can easily stretch their legs. There is a seating space for five people in total in the front and rear rows. The design of individual passenger area in the front also makes this vehicle the motorhome with the best riding experience for commuting.
In terms of control system: equipped with an intelligent four-wheel drive system, central differential rear axle differential lock, it is matched with ZF 8AT manual-automatic transmission paddle shifting and column shifter. With the support of a hi-power turbocharged engine, its safety, stability, and trafficability far exceed other off-road motorhomes. In terms of other control facilities, it has main and co-pilot airbags, side airbags, a dual-connected integrated screen, a central multi-functional armrest box, wireless charging, a multifunctional steering wheel, electronic power assistant steering wheel, electronic heating for the steering wheel, electric rearview mirrors, ABS anti-lock braking, ESP vehicle stability system, uphill assist, downhill assist and other functions. It provides comprehensive safety protection and driving experience among products of the same class.
- In terms of vehicle layout: This motorhome adopts a classic five-seat and two-bed layout with three independent areas: an independent five-seat passenger area in the front, an independent living and sleeping area in the middle, and an external storage box at the rear.
- In terms of sleeping facilities: over cab bed size reaches 1.8 meters by 2 meters. It also has a large-sized top skylight and a privacy viewing window. The couches and floatable table can transfer into a murphy bed with a size of 2200*1100 mm.
- In terms of facilities in the motorhome living area: The motorhome living area has a four-person leisure opposite couches with table, an independent motorhome bathroom, a dedicated air conditioner, a coulomb meter, and a dedicated motorhome refrigerator. There also have an independent diesel heater, an independent diesel water heater, a television, an induction cooker, a stainless-steel vegetable washing basin, etc.
- In terms of external facilities of the motorhome: there is an outdoor awning of 3500*3000mm, outdoor lighting, an outdoor folding small table, a dedicated water filling port for the motorhome, an outdoor power access combination, a double-layer American passenger door, boarding steps, an external luggage box, a top-mounted solar panel, and a mains power access port.
- Water and electricity configuration: Standard configuration includes a 95-liter clean water tank, a 40-liter gray water tank, a 12v400ah lithium battery (can be upgraded to 800ah), a 3000w charger-inverter integrated machine, and a 200w solar panel (can be upgraded to 500w).
Following the design elements of automatic transmission, four-wheel drive, and unique lifting top, creating more excellent chassis pickup motorhomes. I believe that such a classic double-row off-road hard-top lifting motorhome can provide a brand-new vehicle experience for enthusiasts who love off-roading, traveling, photography, and fishing.
General Parameters
|
Models code |
QXC5035XLJG |
|
Chassis Brand |
MAXUS |
|
Body Material |
Aluminum alloy, Fiber leather, Heater preserves foam |
|
Engine brand |
Shanghai Motor |
|
Size |
5820mm*2260mm*2280mm |
|
Curb Weight |
3150kg |
|
Gross Vehicle Mass |
3490kg |
|
Seat Number |
5seats |
Chassis Detail
|
Engine Code |
|
|
Engine Displacement |
2.0T |
|
Max Power |
160 kw |
|
Peak torque |
500N.m |
|
Engine type |
Turbocharger |
|
Emission standard |
VI B |
|
Transmission |
8AT |
|
Fuel Type |
Diesel |
|
Fuel Tank Capacity |
80 Liter |
|
Fuel Consumption per 100 kilometers |
8.8 Liter |
|
Suspended, Steering and Brake System |
|
|
Front Suspended System /Rear Suspended System |
McPherson independent suspension/ Air Suspension |
|
Steering Gear |
Mechanical hydraulic booster |
|
Driving mode |
FR/4WD |
|
Braking system |
Front Vented Disc |
|
Brake type |
4-wheel disc brake |
|
Security Configuration |
CDLS & Remote key |
|
Power steering |
|
|
ESC, Electronic -Stability-Controller |
|
|
Brake Assist System |
|
|
Seat-belt |
|
|
Safety Airbag |
|
|
Vehicle Backup Camera |
|
|
Multi-function steering wheel |
RV configurations
|
Sitting and lying system |
Passenger car grade double adjustable seat |
||
|
Main and passenger seats covered |
|||
|
Passenger swivel seat (optional) |
|||
|
Overcab bed 2000 mm*1800mm |
|||
|
Murphy bed 2100mm*1000mm |
|||
|
Cab privacy curtain |
|||
|
Body exterior |
Integrated cabinet |
||
|
E0 grade environment friendly standard RV furniture panels |
|||
|
Electric heated mirrors |
|
Environment friendly RV special floor leather |
|
|
Roof mounted solar power system with flexible solar panel |
Yacht wood floor (optional) |
||
|
Qixing customized manual awning |
Automatic middle door (optional) |
||
|
Car body stickers |
Light weight and environment friendly GMT vehicle interior |
||
|
Outdoor light |
Kitchen system |
RV refrigerator |
|
|
Air conditioning and ventilation system |
Cockpit original driving high-power heating and cooling air conditioner |
Countertop |
|
|
12V variable frequency back KME air conditioner |
Built-in induction cooker |
||
|
Independent fuel heater |
Covered sink for RV |
||
|
Middle door sliding glass window |
Audio and video entertainment system |
Internet entertainment multimedia navigation all-in-one machine |
|
|
Lifting mechanism |
Sturdy roof made by glass fiber reinforced plastics and aluminum alloy |
Waterway system |
Food grade waterway |
|
Spiral lift rod electric lifting platform |
15M food grade external water filling pipe |
||
|
Control Panel |
Gravity water inlet |
||
|
Electrical system |
Vehicle circuit protection system |
110L portable water tank |
|
|
Living area 600AH lithium battery pack |
40L gray water tank |
||
|
Indoor/outdoor AC220V output socket |
External shower system |
||
|
Indoor 12V car USB power interface |
Manual drain valve |
||
|
Indoor 12V car USB power interface Multi-system hierarchical control of lighting fixtures in the car |
Bathroom system |
Pull-out box toilet |
|
|
or portable toilet |
|||
|
Multi-system hierarchical control of lighting fixtures in the car RV external power port (AC220V) |
Semi-open bathroom or open bathroom |
||
|
Fold-able basin |
|||
|
15M external power cord |
|||
|
Charging and inverting all-in-one machine 3000W |
Foldable towel rack |
||
|
Dark colour (metallic paint) |
Interior color |
Gray/White |
|
