Item |
Configuration |
Remarks |
|
|
QXC5048XLJB |
|||
|
Rated Passenger Capacity |
4, 5, 6 |
||
|
Dimensions & Weight |
Overall Dimensions (L×W×H) (mm) |
5990×2400×2830/2850 |
|
|
Curb Weight (kg) |
4087 |
||
|
Max Gross Weight (kg) |
4495/5250 |
||
|
Wheelbase (mm) |
3360 |
||
|
Power System |
Engine Model |
Diesel Puma2.3L UPG |
|
|
Emission Standard |
China 6b |
||
|
Engine Displacement |
2.3L |
||
|
Engine Power |
126KW |
||
|
Torque |
430Nm |
||
|
Transmission |
8AT Automatic |
||
|
Chassis |
Fuel Type & Suspension (F/R) |
Diesel; MacPherson Independent Front / Hotchkiss Rear |
|
|
Drive Type |
4×2 |
||
|
Brake System (F/R) |
Front Ventilated Disc / Rear Solid Disc |
||
|
Chassis Functional Configurations |
Integrated Center Console |
||
|
Electric Front Windows |
|||
|
Driver Airbag + Pretensioned Seatbelts (DAB+PSB) |
|||
|
Passenger Airbag (PAB) |
|||
|
Driver/Passenger Seatbelt Reminder |
|||
|
ESP + Cruise Control |
|||
|
Automatic Headlights |
|||
|
Automatic Windshield Wipers |
|||
|
Tire Pressure Monitoring System (TPMS) |
|||
|
Multi‑function Steering Wheel |
|||
|
Automatic Air Conditioning |
|||
|
Motorhome Functional Configurations |
Integrated FRP Body (Rear Storage) |
||
|
Front Lifting Roof + Folding Waterproof Insulation Curtain |
|||
|
12V DC Synchronous Electric Lifting Cylinders |
|||
|
Special Motorhome Door (with Screen Door) |
|||
|
Sliding Windows (with Screen & Blackout Curtain) |
|||
|
Front Roof Skylight; Manual 3.5m Awning |
|||
|
Electric Retractable Step (Door‑linked) |
|||
|
Rear Spare Tire |
|||
|
Body Decals |
|||
|
Microfiber Leather Cover for Seats & Pillars |
|||
|
Navigation & Reverse Radar |
|||
|
Eco‑friendly Scrub‑resistant Imitation Leather Interior |
|||
|
Insulated Waterproof Floor + Wear‑resistant Eco Plastic Flooring |
|||
|
Overhead Bed with Flip‑down 32″ TV |
|||
|
Multi‑function Integrated Electrical Cabinet |
|||
|
4‑Person Face‑to‑face卡座 + Lift Table |
2 Business Seats |
||
|
Rear Left Bathroom System |
|||
|
Rear Right Kitchen (Gas Stove + Induction + Hood) |
|||
|
Front Right Longitudinal Sofa (Convertible to Bed) |
|||
|
12V Indelib 85L Fridge |
|||
|
Bedroom Partition Curtains & Blackout Curtains |
|||
|
Multi‑purpose Top Cabinets |
|||
|
Front Cabinet with Wash Basin |
|||
|
5L Gas Tank + Combustible Gas Alarm |
|||
|
External Slide‑out Gas Cooker |
|||
|
Pull‑out Toilet |
|||
|
Bathroom Vent Fan |
|||
|
Towel Rack, Cabinet, Mirror, Light, Waterproof Box |
|||
|
4‑Speaker Stereo |
|||
|
Xiaomi Box |
|||
|
400Ah Lithium Battery |
|||
|
300W Solar Panel; 3000W Inverter/Charger |
|||
|
Ceiling Lights & Ambient Light Strips |
|||
|
1P Daikin Inverter Air Conditioner |
|||
|
220V/12V/USB Power Outlets |
|||
|
220V Shore Power Port + 15m Cable |
|||
|
Integrated Control Panel (Water/Power Display) |
|||
|
Combined Water Inlet + Water Pump |
|||
|
180L Fresh Water Tank; 39L Hot Water; 35L Aux Fresh |
|||
|
50L Waste Water Tank + Manual Valve |
|||
|
Diesel Water Heater + Diesel Heater |
|||
|
15m External Water Hose |
|||
|
Whole Vehicle Price (Standard) |
|||
|
Optional Configurations |
Air Suspension |
||
|
Dual 12V Generator |
|||
|
Rear卡座 Skylight |
|||
|
12V Remote Interior Vent Fan |
|||
|
720W Solar Panel |
|||
|
Side Sliding Window (Mosquito Net) |
|||
|
Rear Tow Hitch + 13‑pin Socket |
|||
|
Rear Ladder |
|||
|
Parking 4‑Way Monitor |
Customer‑supplied |
||
|
Insulated Waterproof + Yacht Floor |
|||
|
Bathroom Wash Basin |
|||
|
Front Right Folding Upper Bed |
|||
|
12V Indelib 152L Fridge |
|||
|
Microwave |
|||
|
External Diesel Cooker |
|||
|
Mini Washing Machine |
|||
|
12V 24″ Outdoor TV |
|||
|
800Ah Lithium Battery |
