RV Description
As an excellent versatile motorhome, Starlight JMC Chassis Affordable Camper Van find out the balance between quality and price. One side, 20 years Qixing RV controls the quality strictly. Another side, the cost also be reasonable reduced due to the mass-produce. Well-known for its powerful engine, comfortable control system, spacious indoor space, high-quality curved finish, varies layouts, complete configurations, Starlight JMC Chassis Affordable Camper Van become a popular model in the RV market and win the market from home and aboard.
Sturdy JMC Chassis with Powerful Engine. The sturdy JMC chassis equipped with powerful diesel engine and advanced 8 AT transmission system. The 2.0 liters turbocharger Puma technology diesel engine have 107 KW max power and 355 N.m peak torque. 8AT transmission is comfortable and convenient. Keyless entrance and one button start also standard facilities of this motorhome.
Varies Layout and Floorplan. In terms of layout,Starlight JMC Chassis Affordable Camper Van has 9 layouts base on three different versions, they are travel version, business travel version, rear kitchen bathroom version. Moreover, the interior color and panel style can be personalized according to the needs of clients.
Versatile scenarios. Starlight JMC Chassis Affordable Camper Van is multifunction motorhome for solo, couple and family and more. Solo traveler can use it as a mobile office and freedom cozy home on the way. Couple can enjoy whole year honeymoon journey with this motorhome. Family can use this motorhome for weekend trip and daily tariffication. Retiree can use this motorhome fulfil their global travel dream.
High-quality Curved Finish. The grace curved finish is anywhere of this stunning motorhome. From the cabin door to the rear end, from floatable table to the cabinet, from the kitchen counter to the bed panel, we can find out the curved finish from exterior to interior of this motorhome.
Professional Waterway and Electricity System. In terms of specific water and electricity configurations. There has a full food-grade waterway system equipped with four water tanks: clean water tank, hot water tank, sewage tank, and black water tank.
The vehicle-grade wiring harness of the whole vehicle is equipped with, a 400Ah lithium iron phosphate energy storage battery that can be upgraded to 800Ah. A selected 3000-watt inverter charger machine machine and the top-mounted solar panels can be upgraded from 200 watts to 400 watts.
Completely Configurations and Incredible Sleep Area. Take the advantages of exquisite interior space arrange, Starlight JMC Chassis Affordable Camper Van installed completely facilities.
The sleep area is spacious and don't occupy any interior space. Regular vertical bed size is 1900mm* 1300mm, turn over the panel will become a storage area. 4 seats and floatable table can transfer into a murphy bed host a 2000mm*850 mm size. Electricity hammock is a optionable choice.
In terms of kitchens, Starlight JMC Chassis Affordable Camper Van have indoor kitchen and outdoor kitchen. Standard equipped with stainless basin, induction cooker, RV fridge. Optional facilities include micro-oven, diesel stove.
Expansion toilet make sure there have well-equipped bath and toilet facilities, also make sure the spacious aisle. There have hot and cold-water shower system, drain and portable toilet stool.
Air-condition and independent diesel heater provide a comfortable environment at anywhere and any season.
General Parameters
|
Models code |
QXC5047XLJD |
|
Chassis Brand |
JMC |
|
Body Material |
Fiber leather, Heater preserves foam |
|
Dimensions |
5998mm*2098mm*2660mm |
|
Curb Weight |
3160kg |
|
Gross Vehicle Mass |
4250kg |
|
Seat Number |
4-6 seats |
Chassis Detail
|
Engine Code |
JX4D20A6H |
|
Engine Displacement |
2.0T |
|
Max Power |
10 kw/ 00 rpm |
|
Peak torque |
350N.m / 3000rpm |
|
Engine type |
Turbocharger |
|
Emission standard |
VI B |
|
Transmission |
8AT |
|
Max Speed |
155 km/ hour |
|
Fuel Type |
Diesel |
|
Fuel Tank Capacity |
80 Liter |
|
Fuel Consumption per 100 kilometers |
8.8 Liter |
|
Suspended, Steering and Brake System |
|
|
Front Suspended System /Rear Suspended System |
McPherson independent suspension/ Air Suspension |
|
Steering Gear |
Mechanical hydraulic booster |
|
Driving mode |
FR |
|
Braking system |
Front Vented Disc |
|
Brake type |
4-wheel disc brake |
|
Security Configuration |
CDLS & Remote key |
|
Power steering |
|
|
ESC, Electronic -Stability-Controller |
|
|
Brake Assist System |
|
|
Seat-belt |
|
|
Safety Airbag |
|
|
Vehicle Backup Camera |
|
|
Multi-function steering wheel |
RV configurations
|
Sitting and lying system |
Passenger car grade double adjustable seat |
|||
|
Main and passenger seats covered |
||||
|
Passenger swivel seat (optional) |
||||
|
Movable dining table or swivel sub-table |
||||
|
Integrated cabinet |
||||
|
Body exterior |
E0 grade environment friendly standard RV furniture panels |
|||
|
Electric heated mirrors |
||||
|
Roof mounted solar power system with flexible solar panel |
|
Environment friendly RV special floor leather |
||
|
Qixing customized manual awning |
Yacht wood floor (optional) |
|||
|
Car body stickers |
Automatic middle door (optional) |
|||
|
Outdoor light |
Light weight and environment friendly GMT vehicle interior |
|||
|
Cockpit original driving high-power heating and cooling air conditioner |
Kitchen system |
RV refrigerator |
||
|
Air conditioning and ventilation system |
12V variable frequency back KME air conditioner |
Countertop |
||
|
Independent fuel heater |
Built-in induction cooker |
|||
|
Middle door sliding glass window |
Covered sink for RV |
|||
|
Food grade waterway |
Audio and video entertainment system |
Internet entertainment multimedia navigation all-in-one machine |
||
|
Waterway system |
15M food grade external water filling pipe |
|||
|
Gravity water inlet |
||||
|
Control Panel |
||||
|
Electrical system |
Vehicle circuit protection system |
|
110L portable water tank |
|
|
Living area 600AH lithium battery pack |
40L gray water tank |
|||
|
Indoor/outdoor AC220V output socket |
External shower system |
|||
|
Indoor 12V car USB power interface |
Manual drain valve |
|||
|
Indoor 12V car USB power interface Multi-system hierarchical control of lighting fixtures in the car |
Bathroom system |
Pull-out box toilet |
||
|
or portable toilet |
||||
|
Multi-system hierarchical control of lighting fixtures in the car RV external power port (AC220V) |
Semi-open bathroom or open bathroom |
|||
|
Fold-able basin |
||||
|
15M external power cord |
||||
|
Charging and inverting all-in-one machine 3000W |
Foldable towel rack |
|||
|
|
Color |
White / black |
||
